GENERADOR 20kVA TRIFÁSICO
$6.960.000
GENERADOR 20 kVA TRIFÁSICO Y DIÉSEL
| GENERADOR DIESEL | GEN20-3PD | |
| Generator Phase |
|
|
| Generator Max.Power KW | 16KW | |
| POTENCIA NOMINAL KW | 16 | |
| POTENCIA MAXIMA LTP KW | 17,6 | |
| Generator Max.Power kVA | 20kVA | |
| Generator Rated voltage | 220V/380V | |
| Frecuencia (Hz) | 50 | |
| Generator Rated current | 42.1A | |
| Generator Rated rotation speed (rpm) | 3000/3600 | |
| Generator Starting system | Key start | |
| Generator Excitation mode | Self-excitation and constant voltage(with AVR) | |
| Generator Power factor[COSΦ] | 0,8 | |
| Protection class | CLASE F | |
| Generador ISO | ISO 8528 | |
| Protección Alternador | IP23 | |
| Sound Level dB(A) Full load at 7M | 70-75 | |
| Engine Brand | FAWDE | |
| Engine Model | DW91-29D-YFD10W | |
| Engine Output | 28HP | |
| Engine Bore × stroke | 90*100mm | |
| Engine Type | Water-cooled, 4-stroke | |
| Engine Power | 23KW | |
| Engine Intake Type | Natural Aspiration | |
| Engine NO.Cylinders | 4 | |
| Engine Displacement | 2.54L | |
| Engine Lubrication system | Direct injection | |
| Engine Lube oil brand | SAE 10W50，SAE 15W50 | |
| Engine Fuel Type | DIESEL | |
| Engine Fuel consumption | 4.47L/H | |
| Engine Rube oil volume | 8L | |
| Generation Fuel tank capacity | 38L | |
| Generation running time | 8H | |
| Generator Net | 850 | |
| Generator Packing size (mm) | 1950*850*1150 | |
| SOCKET | / | |
| / | ||
| Generator Feature | Keystart（button start) ,Voltmeter, AC Output Socket, AC Circuit Breaker, Oil Alert ,control panel | |
| EMERGENCY BUTTON | SI | |
| ATS CONNECTOR & ATS BOX | NO | |
| Alternator Brand Model | BS184E | |
| Alternator | 16KW/20KVA | |
| Alternator Power Efficiency | 88,50% | |
| CONTROLLER | Smartgen/HGM6120 | |
| Battery | 45A |
| Peso | 850 kg |
|---|---|
| Dimensiones | 195 × 85 × 115 cm |
